Aidmer78-021/022 PTFE Sheet/Coil







Material

PTFE Sheet / PTFE In Roll is made from PTFE resin and prepared by compression molding and skiving. It has excellent corrosive resistance, no aging, non-sticking property and lowest friction coefficient and can be used as corrosive resistant lining, support block, lathe guide and electric component at the temperature of -180~260

Characteristics:

♦ Superior endurance in corrosion
♦ Non-flammable,limited oxygen index is under 90.
♦ Low friction coefficient
♦ Non-viscous, Self-lubricating
♦ Superior endurance in high & low temperature, can be used -200~260

♦ High electrical insulation
♦ Atmospheric aging resistance
♦ Low permeability, good gas barrier property
♦ Good physiological compatibility and anti-thrombotic



Applications:

♦ Corrosion resistance: widely used in all chemical containers and parts which contacted with corrosive media, such as tanks, reactors, equipment lining, valves, pumps, fittings, filter materials, separation materials and pipe for corrosive fluids.


♦ Abrasion resistance: can be used as a self lubricating bearing, piston rings, seal rings, gaskets, valve seats, sliders and rails etc..


♦ Insulation materials: mainly used in the manufacture of various products with high temperature resistance, high-frequency resistance, electrical insulation and arc resistance, such as high-frequency cables, moisture-resistant cables, capacitor coils, insulating cover for wire, etc..


♦ Non-stick materials: can be used for non-stick coating such as non-stick pan and non-stick roller for food processor.

Physical Properties

Item

Unit

Standard value

Test method

Density

g/cm3

2.102.30

-

Color

-

Black

-

Tensile Strength

MPa

≥15.0

GB/T 1040.3-2006

Tensile Elongation

%

≥150

GB/T 1040.3-2006

Dielectric Strength

Kv/mm

≥10

IEC 60243-2:2001

Continuous Use Temperature

-80260

ASTM D4894





Size

Item

Thickness

(mm)

Thickness Tolerance

(mm)

Width

(Mts)

Width Tolerance

(mm)

Length

Mts

Aidmer78-021

0.5-3.0

±0.1mm

0.1~1.5

±3mm

As Required

3.5-6.0

±0.15mm

0.1~2.0

±3mm

8.0-12.0

±0.2mm

0.1~2.0

±3mm

Aidmer78-022

15-80mm

±0.3~±0.5mm

0.1~1.2

±5mm

As required
